HD to USB capture Card

DVI HDMI VGA to USB3.0 Capture Card Model DVI-PRO

4K PRO BOX is a HD video capture device which support multi video signal input (DVI/HDMI/VGA) and USB3.0 output. It support max. 4K video input, and 1080P 60fps output, and also HDMI loop out at mean time. The device matched UVC/UAC standard, compatible with Windows,Linux,Android and MAC system. It's a driver free, plug and play HD AV capture device.
  • Details

Features:

> DVI/VGA/HDMI video input

> USB3.0 output and HDMI loop out

> Audio/Microphone input, audio mixing available.

> Standard UVC/UAC

> Max. 4K input, 1080P 60FPS output

> Free driver, plug and play

> Windows, Linux, Android and Mac system support




Specification：

Input port

DVI，HDMI，VGA

Output port

USB3.0，HDMI

Audio port spec.

3 grades 3.5mm jack, 4 grades 3.5mm jack

Video output resolution

1920*1080、1600*1200、1360*768、1280*1024、1280*960、1280*720、1024*768、800*600、720*480、720*576、640*480

Video format

YUY2，MJPEG

Frame

60/50/40/30/25/15/10 and so on

AV protocal

Standard UVC/UAC

Driver

Free driver, plug and play

Operation System

Windows/Linux/Android/MAC

Software

PC camera,OBS,Potplayer (windows)

Consumption

＜3Wat

Working Temp.

-20℃~65℃

Working Humi.

5%-90%

Size

102mm*82mm*25mm

Weight

device：200g， full set：650g
